Cost advantage of even layer printed circuit board (PCB)

PCB designers may design odd numbered printed circuit boards.

If cabling does not require additional layers, why use it? Won't reducing layers make the board thinner? If the circuit board is one layer less, wouldn't the cost be lower? However, in some cases, adding a layer will reduce the cost.

Since there is one less layer of medium and foil, the cost of raw materials for odd PCB is slightly lower than that for even PCB. However, the processing cost of odd PCB is significantly higher than that of even PCB. The processing cost of the inner layer is the same; However, the foil/core structure obviously increases the processing cost of the outer layer.

On the basis of core structure process, non-standard laminated core layer bonding process should be added to odd PCB. Compared with the core structure, the production efficiency of the factory adding foil outside the core structure will decrease. Before laminating and bonding, the outer core requires additional process treatment, which increases the risk of outer layer being scratched and etched incorrectly.

Balanced structure to avoid bending

The best reason to design PCB without odd layers is that odd layers are easy to bend. When the PCB is cooled after the multilayer circuit bonding process, the different laminating tensions of the core structure and the foil structure will cause PCB bending when they are cooled. With the increase of PCB thickness, the risk of PCBA OEM composite PCB bending with two different structures is greater. The key to eliminating PCB bending is to use balanced stacking. Although the bent PCB to a certain extent meets the specification requirements, the subsequent processing efficiency will be reduced, resulting in increased costs. Because special equipment and process are required during assembly, the accuracy of component placement is reduced, which will damage the quality.

Use Even PCB

When odd PCB layers appear in the design, the following methods can be used to achieve balanced lamination, reduce PCB manufacturing cost, and avoid PCB bending. The following methods are arranged in order of preference.

1. One layer of signal layer and use. This method can be used if the power supply layer of the PCB is even and the signal layer is odd. The added layer does not increase the cost, but it can shorten the delivery time and improve the PCB quality.

2. Add an additional power layer. This method can be used if the power supply layer of the design PCB is odd and the signal layer is even. A simple method is to add a layer in the middle of the stack without changing other settings. First, wire according to the odd number of PCB layers, then copy the layers in the middle, and mark the remaining layers. This is the same as the electrical characteristics of the thickened layer foil.

3. Add a blank signal layer near the center of the PCB stack. This method minimizes stack imbalance and improves PCB quality. First, wire according to the odd number of layers, then add a blank signal layer and mark the remaining layers. It is used in microwave circuit and mixed medium circuit (the medium has different dielectric constant).
