How to solve the common problems after circuit board welding

But in the general design can not use the case of BGA packaging as far as possible not to use, the reason is that BGA packaging is difficult to weld, can not check the packaging inside the solder situation.

Circuit board short circuit: when the circuit board welding after the aging process will be found in some circuit board short circuit, out of the circuit board design and electronic original device problems, can be found from the following aspects when the circuit board soldering tin eating time is too short, resulting in poor welding. The activity of the flux itself is not strong, which weakens the wettability of the solder and its expansibility. The direction of the circuit board into the tin and the direction of the tin wave is opposite, the solder liquid surface oxide too much affect the welding.

Solder after the tin point dull grey: solder after the tin point is found to be dull, from two aspects, one is the degree of solder is too low. Circuit board welding. Solder solder to contain more than 50% tin solder spot will have luster. On the other hand, the residue of flux stays on the surface of the tin spot without cleaning and its acid corroded solder spots will also cause the tin spot gray luster.

After soldering, the surface of the tin point is rough: the roughness of the surface of the tin point should first be from the quality of the solder, the solder itself contains a variety of small amounts of metal elements, when the content of these metal elements exceeds its limit will affect the surface of the tin point. When soldering, the surface of the tin liquid is required to be free of impurities. When the surface of the tin liquid is oxidized too much, it should be cleaned up in time, otherwise it will affect the surface of the tin point.

Yellow solder joint color: Yellow solder joint color is a common problem, many people do not know the reason. When the color of the solder appears, there is generally a considerable relationship with the temperature. When the solder temperature is too high, the surface of the liquid tin appears yellow. At this time, it is necessary to adjust the temperature of the tin furnace to the appropriate operating temperature.

How to save cost and maintain quality of the circuit board

In recent years, with the increase of labor cost and raw material price again and again, many customers began to require product price reduction to save costs. circuit board manufacturers just located in the middle of the whole food chain, we do circuit board, the next to face plate suppliers and other auxiliary material suppliers of the price, to face the customer requirements of the price reduction, but also in the face of the growth of labor costs, we all racking their brains to think of how to save costs and to ensure quality.

Batch delivery of the circuit board is based on the basis of proofing, only after the sample qualified, the product can be mass-produced. If the size of the product is large, the one-time production can be satisfied. However, if the size of the product is small, the one-time material will produce inventory after delivery. If the customer samples are directly mass produced through OK, less material can be added during mass production. Can empty the inventory, but if the customer sample test is unqualified, need to revise, then the inventory can only be scrapped.

In order to solve this problem, we can choose the same material, the same plate thickness and the same process of the product, and make it together, which has achieved the effect of reducing inventory and saving cost.

When the appearance of customers' products is irregular, we can not according to the ordinary style of the plate, according to its different shapes, design inverted, concentric circles or two large boards with small boards in the middle of the way to improve the utilization rate of the board, save costs.
