The causes of plate bending and warping and the ways to prevent it

Causes of plate bending and warping

1. The copper surface area on the printed circuit board is uneven, which will worsen the bending and warping of the board.

Generally, a large area of copper foil will be designed on the circuit board for grounding, and sometimes Vcc layer will also be designed with a large area of copper foil. When these large areas of copper foil are not evenly distributed on the same circuit board, it will cause the problem of uneven heat absorption and heat dissipation speed. Of course, the circuit board will also expand and shrink. If the expansion and contraction cannot be done at the same time, it will cause deformation under different stresses. At this time, if the temperature of the board has reached the upper limit of Tg value, the board will begin to soften, resulting in permanent deformation.

2. Link points (vias) on each layer of the board limit board growth and shrinkage

Most of today's circuit boards are multilayer boards, and there will be a connection point (via) like rivets between layers, and the link point is divided into through holes, blind holes and buried holes. The place with the link point will limit the effect of the board's cooling and shrinkage, and will indirectly cause the bending and bending of the board.

3. The weight of the circuit board itself will cause the board to sag

General back welding furnace will use the chain to drive the circuit board forward in the back welding furnace, that is, to both sides of the board when the fulcrum to prop up the whole board, if the board above the excess parts, or the size of the board is too large, it will be due to its own kind of amount and show the middle depression phenomenon, resulting in bending.

4. The depth of V-Cut and the connection strip will affect the deformation of the plate

Basically, V-Cut is the culprit of damaging PCB board structure, because V-Cut is in the original a large sheet of board cut out V-shaped grooves, so the V-Cut place is prone to deformation.

How can we prevent the bending and warping of the plate after the back welding furnace?

1. Reduce the influence of temperature on the stress of the plate

Since (temperature) is the main source of plate stress, so as long as the temperature of the backwelding furnace or slow down the temperature and cooling rate of the plate in the backwelding furnace, the bending and warping of the plate can be greatly reduced. But there may be other side effects, such as a short circuit in the solder.

2. High Tg plate is used

Tg is the glass conversion temperature, that is, the temperature at which the material changes from glass state to rubber state. The lower the Tg value is, the faster the board will become soft after entering the backwelding furnace, and the longer it will take to become soft rubber state, the more serious the deformation of the board will be. The plate with higher Tg can increase its ability to withstand stress and deformation, but the price of the material is relatively high.

3. Increase the thickness of the PCB circuit board

Many electronic products in order to achieve the purpose of thinner, the thickness of the board has been left 1.0mm, 0.8mm, and even 0.6mm thickness, such a thickness to keep the board in the welding furnace without deformation, really a bit of force, it is suggested that if there is no light and thin requirements, the board can use the best thickness of 1.6mm, Can greatly reduce the risk of bending and deformation of the plate.

4. Reduce the size of the circuit board and reduce the number of boards

Since most backwelding furnaces use chains to drive the circuit board forward, the larger the size of the circuit board will sag and deform in the backwelding furnace because of its own weight, so try to put the long side of the circuit board as the board side on the chain of the backwelding furnace, you can reduce the weight of the circuit board caused by the sag deformation, reduce the number of plates is also based on this reason, That is to say, when the furnace, as far as possible to use the narrow side of the vertical direction of the furnace, can achieve the lowest depression deformation.

5. The tray fixture has been used

If the above methods are difficult to achieve, reflow carrier/template is used to reduce the deformation. The reason why the plate bending and warped can be reduced by the reflow carrier/template is that the tray is expected to hold the circuit board no matter it is hot expansion or cold contraction. After the temperature of the circuit board is lower than Tg value and begins to harden again, It can also maintain the size of the garden.

If a single layer of tray can not reduce the deformation of the circuit board, it is necessary to add a layer of cover, the circuit board with two layers of tray clip up, so that you can greatly reduce the circuit board over the welding furnace deformation problem. But the trays are expensive, and you have to add labor to place and retrieve them.

6. Use the Router instead of the V-Cut

Since V-cuts can damage the structural strength of the board, try not to use V-Cut subboards, or reduce the depth of the V-Cut.
